Why I built Paint

Whenever I wanted to make a very small edit on my Debian laptop, crop a screenshot, add a quick arrow, or block out a small area, the system only had GIMP for editing images. Powerful, but heavy and slow for tiny, frequent tasks. I wanted something nimble: quick to open, easy to use, and focused on the common one-off edits people do dozens of times a day.

This project started from that itch and grew into a polished, compact Swing-based application (with GraalVM native builds and platform installers). The goal remains the same: make the small workflows lightning fast.

Short feature summary

  • Core drawing tools

    • Pencil: freehand drawing with adjustable stroke width.
    • Eraser: erases by drawing in white.
    • Highlighter: semi-transparent marker (separate highlight layer so strokes don’t darken when overlapped).
    • Bucket fill: scanline/flood-fill algorithm.
    • Line and Arrow tools (arrowheads scale with stroke/length).
    • Shapes: rectangle, rounded rectangle, oval (stroke and filled variants).
    • Text tool: inline text editor with font family, size, and color.

  • Editing & image handling

    • Move/Cut selection: rectangular marquee, cut into a pending image for repositioning.
    • Image placement mode: paste/drag-drop/open an image, drag to position, commit with Enter or cancel with Esc.
    • Crop to selection(Ctrl+Shift+X) and Crop to last pasted image size.
    • Clipboard paste (Ctrl+V) and drag & drop support for images/files.
    • Undo / Redo history (snapshot based, configurable cap ~25).

  • UI & UX

    • RibbonBar + compact SideMenu (MS Paint copied badly☺️) for quick access.
    • Color palette with More… color chooser (JColorChooser), stroke size slider, highlighter opacity.
    • Canvas size controls in the status bar (spinner for width/height + Resize button).
    • Custom cursors per tool, placement tooltip that stays visible during placement.
    • Keyboard shortcuts: New, Open, Save, Undo, Redo, Exit, and placement accept/cancel keys.

  • File formats & packaging

    • Save flattened result as PNG.
    • Open images using ImageIO-supported formats.
    • Build with Maven; GraalVM native-image profile to create a native binary.
    • jpackage-based installers for MSI and DEB and RPM generated natively from bash and CI workflows that produce native artifacts.

Development timeline (high-level commit history)

This timeline is extracted from the project’s git history to tell the story of how Paint evolved.

  • 2025-11-03, initial commit, project foundation and first implementation.
  • 2025-11-04, undo/redo functionality and keyboard shortcuts were added, UI/ribbon alignment improved.
  • 2025-11-05, File→Open added; installer scaffolding and CI release flows introduced (installer dev release commits).
  • 2025-11-05, reachability metadata updates and Linux packaging/icon tweaks for installers.
  • 2025-11-06, FlatLaf integration for modern look & feel; canvas size controls wired into status bar; tests improved.
  • 2025-11-06, OS-specific native-image packaging settings and multi-line app description support for installers.
  • 2025-11-07, reachability metadata and DEB packaging refinements.
  • 2025-11-08, Transparent Highlighter and Drawing Arrows added; crop behavior and image placement refined; open image from CLI arguments.
  • 2025-11-10, CI consolidation: native-image builds and OS packaging unified into a single workflow; Linux/macOS packaging improvements.
  • 2025-11-11, final release staging and small fixes for canvas sizing and GUI status synchronization.

For the exact commit list and messages, see the repository’s git log history.

How it works (implementation notes)

  • Canvas model: the app uses a persistent BufferedImage as the backing canvas (DrawArea.cache) and a separate transparent highlightLayer for the highlighter tool. This makes highlights non-accumulating and easy to composite.
  • Drawing: continuous tools (pencil, eraser, highlighter) commit during dragging for a responsive feel; shapes/lines/arrow/bucket commit at mouse release (with an undo snapshot taken appropriately).
  • Image placement: pasted or opened images are shown as a pending overlay with a dashed border; the user can drag them, press Enter to accept (commits to the backing image), or Esc to cancel (restores any cut area if moving a selection).
  • Undo/Redo: snapshot-based (base + highlight) with a capped history size to keep memory usage bounded.
  • Packaging: Maven profiles for native (-Pnative) and installer (-Pinstaller) builds; CI workflows prepare and upload native and installer artifacts automatically.

Try it locally

Requirements: Java (JDK 25+ recommended), Maven 3.6+.

Build and run the JAR:

cd /home/ozkan/projects/paint
mvn -q clean package
java -jar target/paint-1.0.0.jar

Open an image directly from the command line:

java -jar target/paint-1.0.0.jar /path/to/screenshot.png

GraalVM native (optional):

export JAVA_HOME=/path/to/graalvm
export PATH="$JAVA_HOME/bin:$PATH"
gu install native-image  # if needed
mvn -Pnative -DskipTests -q clean package
./target/paint

Packaging: there are helper scripts in src/installer/ci/bin/ and a Maven installer profile that uses jpackage to produce platform installers (DEB, DMG, MSI). See the README for details.

Roadmap (next steps)

  • UX

    • Zoom & pan, and a small navigator view for precise work.
    • Optional snapping/guides for aligning placed images and shapes.

  • Features

    • Add an in-app copy-to-clipboard export of the flattened image (so you can copy edits back to your clipboard without saving a file).
    • Optional basic layer support to allow non-destructive edits.
    • Export JPEG and other formats.

  • Distribution

    • Sign macOS apps and Windows MSIs for official releases.
    • Publish packages to a stable GitHub Release and optionally a Linux package repo.

  • Tests & CI

    • Add GUI smoke tests and small image-based regression tests for flood-fill and cropping.

Notes & credits

This app is intentionally lightweight and focuses on the frequent day-to-day editing tasks where a full image editor is overkill. The project uses FlatLaf for modern theming and includes helper scripts and CI workflows to build native binaries and installers.
